Specifications
| Category | Model | Model | Rated | Operating | Current | Power | Speed | Max. Air Flow | Max.Static Pressure | Noise | ||
| Voltage | Voltage | |||||||||||
| (VDC) | (VDC) | (AMP) | (Watts) | (RPM) | (CFM) | (m³/min) | (mm-H2O) | (pa) | (dBA) | |||
| DC Fan CAPITAL | 70×70×25mm DC Fan | CPT7025/12L | 12 | 7~14 | 0.18 | 2.16 | 3000 | 28.12 | 0.80 | 2.72 | 26.66 | 31.90 |
| CPT7025/12M | 0.25 | 3.00 | 4000 | 38.56 | 1.09 | 5.12 | 50.18 | 38.15 | ||||
| CPT7025/12H | 0.49 | 5.88 | 5000 | 47.31 | 1.34 | 7.79 | 76.34 | 43.00 | ||||
| CPT7025/12E | 0.60 | 7.20 | 5500 | 52.09 | 1.48 | 9.27 | 90.85 | 45.07 | ||||
| CPT7025/12U | 1.20 | 14.40 | 7000 | 66.77 | 1.89 | 14.85 | 145.53 | 50.30 | ||||
| CPT7025/24L | 24 | 15~27 | 0.08 | 1.92 | 3000 | 28.12 | 0.80 | 2.72 | 26.66 | 31.90 | ||
| CPT7025/24M | 0.15 | 3.60 | 4000 | 38.56 | 1.09 | 5.12 | 50.18 | 38.15 | ||||
| CPT7025/24H | 0.25 | 6.00 | 5000 | 47.31 | 1.34 | 7.79 | 76.34 | 43.00 | ||||
| CPT7025/24E | 0.32 | 7.68 | 5500 | 52.09 | 1.48 | 9.27 | 90.85 | 45.07 | ||||
| CPT7025/24U | 0.50 | 12.00 | 7000 | 66.77 | 1.89 | 14.85 | 145.53 | 50.30 | ||||
| CPT7025/48L | 48 | 30~55 | 0.05 | 2.40 | 3000 | 28.12 | 0.80 | 2.72 | 26.66 | 31.90 | ||
| CPT7025/48M | 0.08 | 3.84 | 4000 | 38.56 | 1.09 | 5.12 | 50.18 | 38.15 | ||||
| CPT7025/48H | 0.15 | 7.20 | 5000 | 47.31 | 1.34 | 7.79 | 76.34 | 43.00 | ||||
| CPT7025/48E | 0.20 | 9.60 | 5500 | 52.09 | 1.48 | 9.27 | 90.85 | 45.07 | ||||
| CPT7025/48U | 0.30 | 14.40 | 7000 | 66.77 | 1.89 | 14.85 | 145.53 | 50.30 | ||||
| CPT7025/12L | 12 | 7~14 | 0.18 | 2.16 | 3500 | 31.98 | 0.91 | 4.59 | 45.01 | 37.20 | ||
| CPT7025/12M | 0.25 | 3.00 | 4000 | 35.13 | 0.99 | 5.50 | 53.94 | 40.20 | ||||
| CPT7025/12H | 0.49 | 5.88 | 5000 | 44.05 | 1.25 | 8.81 | 86.40 | 45.10 | ||||
| CPT7025/12E | 0.60 | 7.20 | 5500 | 47.78 | 1.35 | 10.63 | 104.24 | 47.30 | ||||
| CPT7025/12U | 1.20 | 14.40 | 6500 | 56.63 | 1.60 | 14.53 | 142.49 | 50.20 | ||||
| CPT7025/24L | 24 | 15~27 | 0.08 | 1.92 | 3500 | 31.98 | 0.91 | 4.59 | 45.01 | 37.20 | ||
| CPT7025/24M | 0.15 | 3.60 | 4000 | 35.13 | 0.99 | 5.50 | 53.94 | 40.20 | ||||
| CPT7025/24H | 0.25 | 6.00 | 5000 | 44.05 | 1.25 | 8.81 | 86.40 | 45.10 | ||||
| CPT7025/24E | 0.32 | 7.68 | 5500 | 47.78 | 1.35 | 10.63 | 104.24 | 47.30 | ||||
| CPT7025/24U | 0.50 | 12.00 | 6500 | 56.63 | 1.60 | 14.53 | 142.49 | 50.20 | ||||
| CPT7025/48L | 48 | 30~55 | 0.05 | 2.40 | 3500 | 31.98 | 0.91 | 4.59 | 45.01 | 37.20 | ||
| CPT7025/48M | 0.08 | 3.84 | 4000 | 35.13 | 0.99 | 5.50 | 53.94 | 40.20 | ||||
| CPT7025/48H | 0.15 | 7.20 | 5000 | 44.05 | 1.25 | 8.81 | 86.40 | 45.10 | ||||
| CPT7025/48E | 0.20 | 9.60 | 5500 | 47.78 | 1.35 | 10.63 | 104.24 | 47.30 | ||||
| CPT7025/48U | 0.30 | 14.40 | 6500 | 56.63 | 1.60 | 14.53 | 142.49 | 50.20 | ||||
