Specifications
| Category | Model | Model Number | Compatible Power for 6-Pulse Rectifier | Carrier Frequency | Rated Current | Inductance | weight | Overall Dimensions | Mounting Dimensions | Mounting Hole Size |
| （KW） | （KHz) | (A) | （mH) | （Kg) | （L*W*H） | （L1*W1） | （A*B) | |||
| Reactor | AC380V Output Reactor | SHKC-2.2 | 2.2 | 4 | 5 | 1.4 | 2.5 | 120*90*160 | 72*52 | 6*11 |
| SHKC-4 | 4 | 4 | 10 | 0.7 | 2.6 | 120*90*160 | 72*52 | 6*11 | ||
| SHKC-5.5 | 5.5 | 4 | 15 | 0.467 | 2.7 | 120*90*160 | 72*52 | 6*11 | ||
| SHKC-7.5 | 7.5 | 4 | 20 | 0.35 | 3.6 | 150*100*190 | 137*53 | 6*11 | ||
| SHKC-11 | 11 | 4 | 30 | 0.234 | 5 | 150*115*190 | 137*66 | 6*11 | ||
| SHKC-15 | 15 | 4 | 35 | 0.2 | 5.2 | 150*115*190 | 137*66 | 6*11 | ||
| SHKC-18.5 | 18.5 | 4 | 40 | 0.175 | 5.6 | 180*115*220 | 165*67 | 8*14 | ||
| SHKC-22 | 22 | 4 | 50 | 0.14 | 6 | 180*115*220 | 165*67 | 8*14 | ||
| SHKC-30 | 30 | 3 | 60 | 0.117 | 7.5 | 180*130*160 | 165*77 | 8*14 | ||
| SHKC-37 | 37 | 3 | 80 | 0.088 | 9 | 180*145*160 | 165*87 | 8*14 | ||
| SHKC-45 | 45 | 3 | 90 | 0.078 | 9.2 | 180*145*160 | 165*87 | 8*14 | ||
| SHKC-55 | 55 | 3 | 110 | 0.064 | 10.6 | 180*155*160 | 165*97 | 8*14 | ||
| SHKC-75 | 75 | 3 | 150 | 0.0467 | 13.3 | 230*150*190 | 210*80 | 8*14 | ||
| SHKC-90 | 90 | 3 | 200 | 0.035 | 16.7 | 230*155*220 | 210*85 | 8*14 | ||
| SHKC-110 | 110 | 3 | 250 | 0.028 | 17 | 230*155*220 | 210*85 | 8*14 | ||
| SHKC-132 | 132 | 3 | 300 | 0.0234 | 24 | 230*180*255 | 210*100 | 8*14 | ||
| SHKC-160 | 160 | 3 | 350 | 0.02 | 24.5 | 230*180*255 | 210*100 | 8*14 | ||
| SHKC-200 | 200 | 3 | 400 | 0.0175 | 25 | 230*180*255 | 210*100 | 8*14 | ||
| SHKC-220 | 220 | 3 | 450 | 0.0156 | 32.7 | 270*200*285 | 245*111 | 11.5*18 | ||
| SHKC-250 | 250 | 3 | 500 | 0.014 | 33.3 | 270*200*285 | 245*111 | 11.5*18 | ||
| SHKC-280 | 280 | 3 | 560 | 0.0125 | 36.4 | 300*205*300 | 275*129 | 11.5*18 | ||
| SHKC-315 | 315 | 3 | 630 | 0.0111 | 36.6 | 300*205*300 | 275*129 | 11.5*18 | ||
| SHKC-350 | 350 | 2 | 720 | 0.0098 | 48.3 | 300*260*300 | 275*149 | 11.5*18 | ||
| SHKC-400 | 400 | 2 | 800 | 0.0088 | 57.8 | 350*250*320 | 325*144 | 11.5*18 | ||
| SHKC-500 | 500 | 2 | 1000 | 0.007 | 65.3 | 350*250*365 | 325*144 | 11.5*18 | ||
| SHKC-560 | 560 | 2 | 1200 | 0.0058 | 69 | 350*260*365 | 325*144 | 11.5*18 | ||
| SHKC-630 | 630 | 2 | 1500 | 0.0047 | 89 | 420*265*450 | 310*122 | 13*23 |
