Specifications
| Category | Model | Model | Rated | Operating | Current | Power | Speed | Max. Air Flow | Max.Static Pressure | Noise | ||
| Voltage | Voltage | |||||||||||
| (VDC) | (VDC) | (AMP) | (Watts) | (RPM) | (CFM) | (m³/min) | (mm-H2O) | (pa) | (dBA) | |||
| DC Fan CAPITAL | 50×50×20mm DC Fan | CPT5020/05L | 5 | 4~6 | 0.12 | 0.60 | 3500 | 9.95 | 0.28 | 1.98 | 19.40 | 24.59 |
| CPT5020/05M | 0.25 | 1.25 | 4500 | 12.49 | 0.35 | 3.19 | 31.26 | 30.05 | ||||
| CPT5020/05H | 0.35 | 1.75 | 5500 | 15.44 | 0.44 | 4.75 | 46.55 | 34.40 | ||||
| CPT5020/05E | 0.50 | 2.50 | 6500 | 18.11 | 0.51 | 6.50 | 63.70 | 38.03 | ||||
| CPT5020/05U | 0.65 | 3.25 | 7500 | 20.72 | 0.59 | 7.11 | 84.08 | 41.14 | ||||
| CPT5020/12L | 12 | 7~14 | 0.08 | 0.96 | 3500 | 9.95 | 0.28 | 1.98 | 19.42 | 24.59 | ||
| CPT5020/12M | 0.10 | 1.20 | 4500 | 12.49 | 0.35 | 3.19 | 31.28 | 30.05 | ||||
| CPT5020/12H | 0.16 | 1.92 | 5500 | 15.44 | 0.44 | 4.75 | 46.58 | 34.40 | ||||
| CPT5020/12E | 0.24 | 2.88 | 6500 | 18.11 | 0.51 | 6.50 | 63.70 | 38.03 | ||||
| CPT5020/12U | 0.35 | 4.20 | 7500 | 20.72 | 0.59 | 7.11 | 84.08 | 41.14 | ||||
| CPT5020/24L | 24 | 15~27 | 0.05 | 1.20 | 3500 | 9.95 | 0.28 | 1.98 | 19.42 | 24.59 | ||
| CPT5020/24M | 0.07 | 1.68 | 4500 | 12.49 | 0.35 | 3.19 | 31.28 | 30.05 | ||||
| CPT5020/24H | 0.09 | 2.16 | 5500 | 15.44 | 0.44 | 4.75 | 46.58 | 34.40 | ||||
| CPT5020/24E | 0.13 | 3.12 | 6500 | 18.11 | 0.51 | 6.50 | 63.70 | 38.03 | ||||
| CPT5020/24U | 0.18 | 4.32 | 7500 | 20.72 | 0.59 | 7.11 | 84.08 | 41.14 | ||||
| CPT5020/05L | 5 | 4~6 | 0.25 | 1.25 | 6000 | 16.23 | 0.46 | 5.72 | 56.06 | 38.44 | ||
| CPT5020/05M | 0.36 | 1.80 | 7000 | 19.53 | 0.55 | 8.86 | 86.83 | 41.78 | ||||
| CPT5020/05H | 0.50 | 2.50 | 8000 | 21.83 | 0.62 | 10.71 | 104.96 | 44.68 | ||||
| CPT5020/05E | 0.75 | 3.75 | 9000 | 24.06 | 0.68 | 13.35 | 130.83 | 47.24 | ||||
| CPT5020/12L | 12 | 7~14 | 0.12 | 1.44 | 6000 | 16.23 | 0.46 | 5.72 | 56.06 | 38.44 | ||
| CPT5020/12M | 0.18 | 2.16 | 7000 | 19.53 | 0.55 | 8.86 | 86.83 | 41.78 | ||||
| CPT5020/12H | 0.25 | 3.00 | 8000 | 21.83 | 0.62 | 10.71 | 104.96 | 44.68 | ||||
| CPT5020/12E | 0.30 | 3.60 | 9000 | 24.06 | 0.68 | 13.35 | 130.83 | 47.24 | ||||
| CPT5020/12U | 0.35 | 4.20 | 10000 | 26.82 | 0.76 | 15.79 | 154.74 | 49.53 | ||||
| CPT5020/24L | 24 | 15~27 | 0.06 | 1.44 | 6000 | 16.23 | 0.46 | 5.72 | 56.06 | 38.44 | ||
| CPT5020/24M | 0.10 | 2.40 | 7000 | 19.53 | 0.55 | 8.86 | 86.83 | 41.78 | ||||
| CPT5020/24H | 0.12 | 2.88 | 8000 | 21.83 | 0.62 | 10.71 | 104.96 | 44.68 | ||||
| CPT5020/24E | 0.15 | 3.60 | 9000 | 24.06 | 0.68 | 13.35 | 130.83 | 47.24 | ||||
| CPT5020/24U | 0.18 | 4.32 | 10000 | 26.82 | 0.76 | 15.79 | 154.74 | 49.53 | ||||
