Specifications
| Category | Model | Model | Rated | Operating | Current | Power | Speed | Max. Air Flow | Max.Static Pressure | Noise | ||
| Voltage | Voltage | |||||||||||
| (VDC) | (VDC) | (AMP) | (Watts) | (RPM) | (CFM) | (m³/min) | (mm-H2O) | (pa) | (dBA) | |||
| DC Fan CAPITAL | 70×70×38mm DC Fan | CPT7038/12L | 12 | 7~14 | 0.25 | 3.00 | 6000 | 42.88 | 1.21 | 12.50 | 122.58 | 39.00 |
| CPT7038/12M | 0.35 | 4.20 | 7000 | 49.79 | 1.41 | 16.15 | 158.38 | 46.00 | ||||
| CPT7038/12H | 0.60 | 7.20 | 8000 | 57.60 | 1.63 | 20.55 | 201.53 | 49.00 | ||||
| CPT7038/12E | 0.85 | 10.20 | 9000 | 66.01 | 1.87 | 24.16 | 236.93 | 52.00 | ||||
| CPT7038/12U | 1.20 | 14.40 | 10000 | 74.19 | 2.10 | 26.20 | 256.93 | 56.00 | ||||
| CPT7038/24L | 24 | 15~27 | 0.13 | 3.12 | 6000 | 42.88 | 1.21 | 12.50 | 122.58 | 39.00 | ||
| CPT7038/24M | 0.25 | 6.00 | 7000 | 49.79 | 1.41 | 16.15 | 158.38 | 46.00 | ||||
| CPT7038/24H | 0.32 | 7.68 | 8000 | 57.60 | 1.63 | 20.55 | 201.53 | 49.00 | ||||
| CPT7038/24E | 0.45 | 10.80 | 9000 | 66.01 | 1.87 | 24.16 | 236.93 | 52.00 | ||||
| CPT7038/24U | 0.60 | 14.40 | 10000 | 74.19 | 2.10 | 26.20 | 256.93 | 56.00 | ||||
| CPT7038/48L | 48 | 30~55 | 0.06 | 2.88 | 6000 | 42.88 | 1.21 | 12.50 | 122.58 | 39.00 | ||
| CPT7038/48M | 0.10 | 4.80 | 7000 | 49.79 | 1.41 | 16.15 | 158.38 | 46.00 | ||||
| CPT7038/48H | 0.16 | 7.68 | 8000 | 57.60 | 1.63 | 20.55 | 201.53 | 49.00 | ||||
| CPT7038/48E | 0.22 | 10.56 | 9000 | 66.01 | 1.87 | 24.16 | 236.93 | 52.00 | ||||
| CPT7038/48U | 0.35 | 16.80 | 10000 | 74.19 | 2.10 | 26.20 | 256.93 | 56.00 | ||||
| CPT7038/12L | 12 | 7~14 | 0.25 | 3.00 | 3000 | 27.07 | 0.77 | 3.11 | 30.48 | 27.05 | ||
| CPT7038/12M | 0.35 | 4.20 | 3500 | 31.79 | 0.90 | 4.24 | 41.55 | 30.39 | ||||
| CPT7038/12H | 0.60 | 7.20 | 4500 | 41.00 | 1.16 | 6.88 | 67.42 | 35.85 | ||||
| CPT7038/12E | 0.85 | 10.20 | 5500 | 51.59 | 1.46 | 9.73 | 95.35 | 40.21 | ||||
| CPT7038/12U | 1.20 | 14.40 | 6500 | 61.52 | 1.74 | 13.28 | 130.14 | 43.84 | ||||
| CPT7038/24L | 24 | 15~27 | 0.13 | 3.12 | 3000 | 27.07 | 0.77 | 3.11 | 30.48 | 27.05 | ||
| CPT7038/24M | 0.25 | 6.00 | 3500 | 31.79 | 0.90 | 4.24 | 41.55 | 30.39 | ||||
| CPT7038/24H | 0.32 | 7.68 | 4500 | 41.00 | 1.16 | 6.88 | 67.42 | 35.85 | ||||
| CPT7038/24E | 0.45 | 10.80 | 5500 | 51.59 | 1.46 | 9.73 | 95.35 | 40.21 | ||||
| CPT7038/24U | 0.60 | 14.40 | 6500 | 61.52 | 1.74 | 13.28 | 130.14 | 43.84 | ||||
| CPT7038/48L | 48 | 30~55 | 0.06 | 2.88 | 3000 | 27.07 | 0.77 | 3.11 | 30.48 | 27.05 | ||
| CPT7038/48M | 0.10 | 4.80 | 3500 | 31.79 | 0.90 | 4.24 | 41.55 | 30.39 | ||||
| CPT7038/48H | 0.16 | 7.68 | 4500 | 41.00 | 1.16 | 6.88 | 67.42 | 35.85 | ||||
| CPT7038/48E | 0.22 | 10.56 | 5500 | 51.59 | 1.46 | 9.73 | 95.35 | 40.21 | ||||
| CPT7038/48U | 0.35 | 16.80 | 6500 | 61.52 | 1.74 | 13.28 | 130.14 | 43.84 | ||||
