Specifications
| Category | Model | Model | Rated | Operating | Current | Power | Speed | Max. Air Flow | Max.Static Pressure | Noise | ||
| Voltage | Voltage | |||||||||||
| (VDC) | (VDC) | (AMP) | (Watts) | (RPM) | (CFM) | (m³/min) | (mm-H2O) | (pa) | (dBA) | |||
| DC Fan CAPITAL | 60×60×38mm DC Fan | CPT6038/12L | 12 | 7~14 | 0.70 | 8.40 | 10000 | 34.18 | 0.97 | 23.85 | 233.73 | 58.10 |
| CPT6038/12M | 1.00 | 12.00 | 12000 | 46.06 | 1.30 | 32.08 | 314.38 | 62.06 | ||||
| CPT6038/12H | 1.20 | 14.40 | 14000 | 47.69 | 1.35 | 43.17 | 423.07 | 65.41 | ||||
| CPT6038/12E | 1.50 | 18.00 | 16000 | 53.55 | 1.52 | 52.14 | 510.97 | 68.31 | ||||
| CPT6038/12U | 2.80 | 33.60 | 18000 | 60.43 | 1.71 | 60.98 | 597.60 | 70.87 | ||||
| CPT6038/24L | 24 | 15~27 | 0.35 | 8.40 | 10000 | 34.18 | 0.97 | 23.85 | 233.73 | 58.10 | ||
| CPT6038/24M | 0.50 | 12.00 | 12000 | 46.06 | 1.30 | 32.08 | 314.38 | 62.06 | ||||
| CPT6038/24H | 0.60 | 14.40 | 14000 | 47.69 | 1.35 | 43.17 | 423.07 | 65.41 | ||||
| CPT6038/24E | 0.80 | 19.20 | 16000 | 53.55 | 1.52 | 52.14 | 510.97 | 68.31 | ||||
| CPT6038/24U | 1.50 | 36.00 | 18000 | 60.43 | 1.71 | 60.98 | 597.60 | 70.87 | ||||
| CPT6038/48L | 48 | 30~55 | 0.16 | 7.68 | 10000 | 34.18 | 0.97 | 23.85 | 233.73 | 58.10 | ||
| CPT6038/48M | 0.25 | 12.00 | 12000 | 46.06 | 1.30 | 32.08 | 314.38 | 62.06 | ||||
| CPT6038/48H | 0.32 | 15.36 | 14000 | 47.69 | 1.35 | 43.17 | 423.07 | 65.41 | ||||
| CPT6038/48E | 0.42 | 20.16 | 16000 | 53.55 | 1.52 | 52.14 | 510.97 | 68.31 | ||||
| CPT6038/48U | 0.65 | 31.20 | 18000 | 60.43 | 1.71 | 60.98 | 597.60 | 70.87 | ||||
| CPT6038/12L | 12 | 7~14 | 0.50 | 6.00 | 10000 | 36.36 | 1.03 | 26.95 | 264.29 | 55.60 | ||
| CPT6038/12M | 0.85 | 10.20 | 12000 | 42.51 | 1.20 | 36.45 | 357.45 | 58.20 | ||||
| CPT6038/12H | 1.50 | 18.00 | 15000 | 52.94 | 1.50 | 54.15 | 531.03 | 62.60 | ||||
| CPT6038/12E | 2.20 | 26.40 | 18000 | 65.35 | 1.85 | 60.05 | 588.89 | 66.70 | ||||
| CPT6038/12U | 3.00 | 36.00 | 21000 | 76.43 | 2.16 | 126.33 | 1238.87 | 75.00 | ||||
| CPT6038/24L | 24 | 15~27 | 0.35 | 8.40 | 10000 | 36.36 | 1.03 | 26.95 | 264.29 | 55.60 | ||
| CPT6038/24M | 0.50 | 12.00 | 12000 | 42.51 | 1.20 | 36.45 | 357.45 | 58.20 | ||||
| CPT6038/24H | 0.80 | 19.20 | 15000 | 52.94 | 1.50 | 54.15 | 531.03 | 62.60 | ||||
| CPT6038/24E | 1.10 | 26.40 | 18000 | 65.35 | 1.85 | 60.05 | 588.89 | 66.70 | ||||
| CPT6038/24U | 1.50 | 36.00 | 21000 | 76.43 | 2.16 | 126.33 | 1238.87 | 75.00 | ||||
| CPT6038/48L | 48 | 30~55 | 0.12 | 5.76 | 10000 | 36.36 | 1.03 | 26.95 | 264.29 | 55.60 | ||
| CPT6038/48M | 0.20 | 9.60 | 12000 | 42.51 | 1.20 | 36.45 | 357.45 | 58.20 | ||||
| CPT6038/48H | 0.35 | 16.80 | 15000 | 52.94 | 1.50 | 54.15 | 531.03 | 62.60 | ||||
| CPT6038/48E | 0.50 | 24.00 | 18000 | 65.35 | 1.85 | 60.05 | 588.89 | 66.70 | ||||
| CPT6038/48U | 0.60 | 28.80 | 21000 | 76.43 | 2.16 | 126.33 | 1238.87 | 75.00 | ||||
