Specifications
| Category | Model | Model | Rated | Operating | Current | Power | Speed | Max. Air Flow | Max.Static Pressure | Noise | ||
| Voltage | Voltage | |||||||||||
| (VDC) | (VDC) | (AMP) | (Watts) | (RPM) | (CFM) | (m³/min) | (mm-H2O) | (pa) | (dBA) | |||
| DC Fan CAPITAL | 172×172×51mm DC Fan | CPT17251/12L | 12 | 7~14 | 1.30 | 15.60 | 3000 | 249.00 | 7.05 | 14.05 | 137.78 | 51.10 |
| CPT17251/12M | 2.60 | 31.20 | 4000 | 328.15 | 9.29 | 25.10 | 246.15 | 61.00 | ||||
| CPT17251/12H | 3.30 | 39.60 | 4500 | 369.03 | 10.45 | 31.10 | 304.99 | 64.20 | ||||
| CPT17251/12E | 4.20 | 50.40 | 5000 | 408.80 | 11.58 | 38.56 | 378.14 | 66.80 | ||||
| CPT17251/24L | 24 | 15~27 | 0.85 | 20.40 | 3000 | 249.00 | 7.05 | 14.05 | 137.78 | 51.10 | ||
| CPT17251/24M | 1.50 | 36.00 | 4000 | 328.15 | 9.29 | 25.10 | 246.15 | 61.00 | ||||
| CPT17251/24H | 2.80 | 67.20 | 4500 | 369.03 | 10.45 | 31.10 | 304.99 | 64.20 | ||||
| CPT17251/24E | 4.60 | 110.40 | 5000 | 408.80 | 11.58 | 38.56 | 378.14 | 66.80 | ||||
| CPT17251/24U | 6.00 | 144.00 | 6000 | 489.60 | 13.87 | 43.60 | 427.57 | 75.20 | ||||
| CPT17251/48L | 48 | 30~55 | 0.35 | 16.80 | 3000 | 249.00 | 7.05 | 14.05 | 137.78 | 51.10 | ||
| CPT17251/48M | 0.70 | 33.60 | 4000 | 328.15 | 9.29 | 25.10 | 246.15 | 61.00 | ||||
| CPT17251/48H | 1.10 | 52.80 | 4500 | 369.03 | 10.45 | 31.10 | 304.99 | 64.20 | ||||
| CPT17251/48E | 1.60 | 76.80 | 5000 | 408.80 | 11.58 | 38.56 | 378.14 | 66.80 | ||||
| CPT17251/48U | 2.20 | 105.60 | 6000 | 489.60 | 13.87 | 43.60 | 427.57 | 75.20 | ||||
| CPT17251/12L | 12 | 7~14 | 2.80 | 33.60 | 4500 | 293.56 | 8.31 | 24.47 | 239.97 | 61.41 | ||
| CPT17251/12M | 3.60 | 43.20 | 5000 | 326.18 | 9.24 | 30.20 | 296.16 | 63.69 | ||||
| CPT17251/12H | 4.50 | 54.00 | 5500 | 358.80 | 10.16 | 36.55 | 358.43 | 65.76 | ||||
| CPT17251/12E | 6.20 | 74.40 | 6000 | 391.41 | 11.08 | 43.49 | 426.49 | 67.65 | ||||
| CPT17251/24L | 24 | 15~27 | 1.30 | 31.20 | 4500 | 293.56 | 8.31 | 24.47 | 239.97 | 61.41 | ||
| CPT17251/24M | 1.80 | 43.20 | 5000 | 326.18 | 9.24 | 30.20 | 296.16 | 63.69 | ||||
| CPT17251/24H | 2.20 | 52.80 | 5500 | 358.80 | 10.16 | 36.55 | 358.43 | 65.76 | ||||
| CPT17251/24E | 3.00 | 72.00 | 6000 | 391.41 | 11.08 | 43.49 | 426.49 | 67.65 | ||||
| CPT17251/24U | 5.00 | 120.00 | 6800 | 424.03 | 12.01 | 54.04 | 529.95 | 75.80 | ||||
| CPT17251/48L | 48 | 30~55 | 0.60 | 28.80 | 4500 | 293.56 | 8.31 | 24.47 | 239.97 | 73.00 | ||
| CPT17251/48M | 1.00 | 48.00 | 5000 | 326.18 | 9.24 | 30.20 | 296.16 | 63.69 | ||||
| CPT17251/48H | 1.50 | 72.00 | 5500 | 358.80 | 10.16 | 36.55 | 358.43 | 65.76 | ||||
| CPT17251/48E | 1.80 | 86.40 | 6000 | 391.41 | 11.08 | 43.49 | 426.49 | 67.65 | ||||
| CPT17251/48U | 2.30 | 110.40 | 6800 | 424.03 | 12.01 | 54.04 | 529.95 | 75.80 | ||||
