In today's rapidly evolving telecommunications and data center landscape, efficient thermal management is no longer optional—it is mission-critical. With the expansion of 5G infrastructure and the growing adoption of high-density 2U and 3U cloud storage servers, airflow constraints and system impedance have become major engineering bottlenecks.
As a thermal solution provider and authorized SANYO DENKI partner, CAPITAL has worked closely with leading OEMs and telecom equipment manufacturers such as ZTE, Huawei, and Hytera. In this case, we share how our engineering team addressed a severe high-impedance airflow challenge using advanced counter rotating fan technology, achieving measurable improvements in cooling efficiency, system stability, and uptime.
Modern telecom cabinets and server architectures are designed to maximize computational density within limited physical space. While this improves performance per unit volume, it significantly reduces the available pathways for airflow.
Key industry trends driving this challenge include:
- Increased component density in compact server enclosures
- Complex cable routing and obstruction within chassis
- Integration of high-power CPUs and GPUs generating concentrated heat loads
- Growing reliance on edge computing and distributed data centers
These factors contribute to a sharp rise in airflow impedance, which directly impacts cooling performance. Traditional axial fans often fail to maintain sufficient airflow under these conditions, leading to inefficient heat dissipation.
During a recent collaboration with a telecom equipment manufacturer, we encountered a critical cooling issue in high-density server systems deployed in 5G infrastructure.
The key challenges included:
- Skyrocketing system impedance
As server components became more densely packed, airflow resistance increased exponentially. The existing cooling system could not overcome the high back pressure.
- Severe airflow degradation
Standard fans experienced significant pressure drops, resulting in reduced airflow and even air backflow within the enclosure.
- Localized thermal hotspots
Critical components such as CPUs and memory modules experienced temperatures as high as 68°C, exceeding safe operating thresholds.
- Operational risks
The overheating led to system throttling, intermittent failures, and potential downtime—posing serious risks to data integrity and network reliability.
From an engineering perspective, this was not just a fan replacement issue—it required a fundamental redesign of airflow dynamics within a constrained environment.
To address the problem, CAPITAL's engineering team conducted a comprehensive thermal analysis using airflow simulation tools and real-world testing.
Our approach focused on three key steps:
1. Airflow simulation and impedance mapping
We analyzed airflow paths, pressure distribution, and obstruction points within the server enclosure to identify bottlenecks.
2. Fan performance evaluation under high static pressure
We tested multiple fan configurations to determine their ability to sustain airflow against increasing resistance.
3. Selection of advanced cooling technology
Based on the findings, we identified that conventional fan systems were insufficient for this high-impedance scenario.
This led us to deploy a specialized solution: the SANYO DENKI San Ace 92 (9CRA type) counter rotating fan.
The SANYO DENKI San Ace 92 counter rotating fan represents a significant advancement in cooling technology, specifically designed for high static pressure environments.
Unlike traditional fans, this model features two impellers rotating in opposite directions within a single frame. This configuration provides several advantages:
- Straightens turbulent airflow into a focused stream
- Reduces energy loss caused by vortex formation
- Improves airflow efficiency through dense obstructions
The counter rotating structure enables the fan to:
- Overcome high back pressure more effectively
- Maintain stable airflow through tight cable arrangements
- Push air through clogged or high-density dust filters
By balancing the front and rear impellers and refining blade angles, the fan achieves superior aerodynamic performance under extreme conditions.
From an engineering standpoint, this solution transforms airflow from a passive process into an actively controlled system, capable of adapting to complex internal environments.
After implementing the counter rotating fan solution, the results were immediate and significant.
The system achieved a maximum static pressure of 1,650 Pa, setting a new benchmark for similar applications. This level of pressure enabled consistent airflow even under extreme impedance.
Compared to conventional serial fan configurations, the new system delivered a 14% improvement in airflow, directly enhancing heat dissipation efficiency.
Internal enclosure temperatures dropped from a critical 68°C to a stable 53°C. This 15°C reduction eliminated thermal hotspots and restored safe operating conditions.
With optimized cooling:
- Heat-induced system crashes were completely eliminated
- CPU throttling was significantly reduced
- Overall system uptime reached 99.9%
These improvements translated into higher reliability for mission-critical telecom infrastructure.
This project also demonstrates CAPITAL's role beyond being a product supplier. As both a manufacturer and SANYO DENKI's key distributor, we provide:
- Customized thermal design support
- Access to industry-leading fan technologies
- Proven experience with global telecom leaders
- End-to-end solution integration
Our collaboration with companies like Huawei, ZTE, and Hytera reflects our ability to meet the stringent requirements of high-performance applications.
High-impedance airflow is one of the most pressing challenges in modern server and telecom design. However, as this case study shows, the right combination of engineering expertise and advanced technology can transform this challenge into a performance advantage.
By leveraging counter rotating fan technology, CAPITAL successfully helped a telecom client overcome severe cooling limitations, improve system stability, and achieve near-perfect uptime.
For businesses operating in high-density computing environments, this approach provides a clear path forward: rethink airflow, adopt high-performance solutions, and prioritize thermal efficiency as a core design principle.
