Specifications
| Category | Model | Model | Rated | Operating | Current | Power | Speed | Max. Air Flow | Max.Static Pressure | Noise | ||
| Voltage | Voltage | |||||||||||
| (VDC) | (VDC) | (AMP) | (Watts) | (RPM) | (CFM) | (m³/min) | (mm-H2O) | (pa) | (dBA) | |||
| DC Fan CAPITAL | 140×140×25mm DC Fan | CPT14025/12L | 12 | 7~14 | 0.08 | 0.96 | 1500 | 66.03 | 1.87 | 2.02 | 19.80 | 33.59 |
| CPT14025/12M | 0.13 | 1.56 | 2000 | 81.43 | 2.31 | 3.23 | 31.65 | 39.84 | ||||
| CPT14025/12H | 0.28 | 3.36 | 2500 | 101.60 | 2.88 | 5.05 | 49.49 | 44.68 | ||||
| CPT14025/12E | 0.60 | 7.20 | 3000 | 132.66 | 3.76 | 7.85 | 76.93 | 48.64 | ||||
| CPT14025/12U | 1.20 | 14.40 | 4000 | 170.10 | 4.82 | 11.52 | 112.90 | 54.89 | ||||
| CPT14025/24L | 24 | 15~27 | 0.05 | 1.20 | 1500 | 66.03 | 1.87 | 2.02 | 19.80 | 33.59 | ||
| CPT14025/24M | 0.11 | 2.64 | 2000 | 81.43 | 2.31 | 3.23 | 31.65 | 39.84 | ||||
| CPT14025/24H | 0.15 | 3.60 | 2500 | 101.60 | 2.88 | 5.05 | 49.49 | 44.68 | ||||
| CPT14025/24E | 0.35 | 8.40 | 3000 | 132.66 | 3.76 | 7.85 | 76.93 | 48.64 | ||||
| CPT14025/24U | 0.70 | 16.80 | 4000 | 170.10 | 4.82 | 11.52 | 112.90 | 54.89 | ||||
| CPT14025/48L | 48 | 30~55 | 0.03 | 1.44 | 1500 | 66.03 | 1.87 | 2.02 | 19.80 | 33.59 | ||
| CPT14025/48M | 0.05 | 2.40 | 2000 | 81.43 | 2.31 | 3.23 | 31.65 | 39.84 | ||||
| CPT14025/48H | 0.08 | 3.84 | 2500 | 101.60 | 2.88 | 5.05 | 49.49 | 44.68 | ||||
| CPT14025/48E | 0.13 | 6.24 | 3000 | 132.66 | 3.76 | 7.85 | 76.93 | 48.64 | ||||
| CPT14025/48U | 0.35 | 16.80 | 4000 | 170.10 | 4.82 | 11.52 | 112.90 | 54.89 | ||||
